Section 2. Installing the PX-760A Internal ATAPI Drive
26 PX-760 Installation and Users Manual
Before PX-760A
Installation
How to Install the
PX-760A
B
Hard disk connected as Master
device, and CD-ROM or DVD-
ROM drive connected as Slave
on the primary IDE port;
nothing connected to
secondary IDE port.
Set the mode jumper to Master,
and connect the PX-760A as
Master to secondary IDE port.
Figure 9. How to install the PX-760A if your computer is originally
set up in configuration B
