Section 2. Installing the PX-760A Internal ATAPI Drive
PX-760 Installation and Users Manual 27
Before PX-760A
Installation
How to Install the
PX-760A
C
Hard disk connected as Master
device on primary IDE port;
nothing connected to
secondary IDE port.
Set the mode jumper to Master,
and connect the
PX-760A as Master to
secondary IDE port.
Figure 10. How to install the PX-760A if your computer is originally
set up in configuration C
