Section 2. Installing the PX-760A Internal ATAPI Drive
28 PX-760 Installation and Users Manual
Before PX-760A
Installation
How to Install the
PX-760A
D
System uses special Cable
Select cables; all devices are
jumpered for Cable Select.
Set the PX-760A’s mode
jumper to CSEL, and connect
the drive to the end of the cable
from the computer’s IDE
interface connector.
Figure 11: How to install the PX-760A if your computer is originally
set up in configuration D
