PLS AR-200 - Functional Overview and Description

10
2 .  F u n c  o n a l  o v e r v i e w  a n d  d e s c r i p  o n 
Figure 3, underside of the AR-200 Ceiling Hoist
Number Explanaon Reference
1 Control lights. Secon 2.3
2 Connecon socket for Hand Control. Secon 2.1.2
3 Hand Control latch. Secon 2.1.2
4 Hoisng belt clip for Hand Control. Secon 2.1.3
5 Hoisng Belt. Secon 2.4.4
6 Central Suspension Point for Spreader Bar. Secon 3.5
7 Height limit switch. Secon 2.4.2
8 Connecon socket for electrical 4-point
Spreader Bar.
Secon 2.5
9 Emergency stop cord. Secon 2.4.3
The parts are dealt with in the specied secons.
