Plusivo DM501D - AC Voltage and Current Specs

6.5 Direct Current DCA
Range
Resolution
Accuracy
60 mA
0.10 mA
±(1.2% + 5)
600 mA
0.01 mA
10 A
10 mA
±(3% + 5)
● Overload protection: mA range with F 200 mA/250V and 20 A range with F10 A/250 V
● For currents greater than 5 A, the test time shall be less than 10 minutes and after such a measurement
one minute shall be allowed to terminate the test.
6.6 Alternative Current ACA
Range
Resolution
Accuracy
60 mA
0.10 mA
±(1.2% + 5)
600 mA
0.01 mA
10 A
10 mA
±(3% + 5)
● Overload protection: mA range with F 60 0mA/250 V and 20 A range with F10 A/250 V
● Max input current: mA: 600 mA RMS 10 A: 10 A RMS
● For currents greater than 5 A, the test time shall be less than 10 minutes and after such a measurement
one minute shall be allowed to terminate the test.
● Frequency response: 10 Hz to 1 KHz true RMS
6.7 Frequency
Range
Resolution
Accuracy
9.999 Hz
0.001 Hz
±(1.5%+5)
99.99 Hz
0.01 Hz
999.9 Hz
0.1 Hz
9.999 KHz
0.001 KHz
99.99 KHz
0.01 KHz
999.9 KHz
0.1 KHz
9.999 MHz
0.001 MHz
Input voltage range: 200 mV-10 V AC RMS
Overload protection: 250 V DC/AC
6.8 Capacitance
Range
Resolution
Accuracy
60 nF
0.01 nF
±(4.0%+5)
600 nF
0.1 nF
6 μF
1 nF
60 μF
10 nF
600 μF
100 nF
6 mF
0.1 μF
100 mF
0.001 mF
Overload protection: 250 V
10
Mastering the Art of Measurement (DM501D Digital Multimeter) r.01 www.plusivo.com
