13.Carefully remove the intake plenum assembly
d
.
14.Remove the fasteners
f
retaining the PTO side
cross brace
g
. Remove the PTO side cross brace.
NOTICE
The PTO side chassis cross brace can either be
removed completely or remove the back bolt only and
swing the tube forward. This makes air box removal
much easier.
15.Remove the fasteners
h
securing the PBR and
carefully move the PBR to the side.
16.Cut the cable tie
j
and disconnect the T-MAP sensor
harness connector
k
.
17.Disconnect the ignition coils connectors
l
from the
wire harness and remove the spark plug caps
1(
from
the spark plugs.
18.Cut the cable tie of the routing clip
2)
securing the
stator wiring harness and throttle cable to the air box.
