3.74
9940259 R02 - 2022 RZR PRO R / PRO R 4 Service Manual
© Copyright Polaris Industries Inc.
ENGINE BLOCK ASSEMBLY
1. If removed, install the engine block alignment dowels.
2. Lubricate the crankshaft position sensor O-ring with
engine oil.
3. Install the crankshaft position sensor. Torque fastener
to specification.
TORQUE
Crankshaft Position Sensor Fastener:
80 in-lbs (9 N·m)
4. Install the knock sensor and fastener. Clock the knock
sensor to the correct orientation. Torque fastener to
specification.
TORQUE
Knock Sensor Fastener:
16 ft-lbs (22 N·m)
ENGINE / COOLING SYSTEM
