BRAKE LINE ROUTING / RETENTION (2-SEAT)
Master Cylinder To Front Brake Calipers
q
Master Cylinder
w
Rivet Clip
e
Routing Clip
r
Front Brake Calipers
Master Cylinder To Junction Block
