9940259 R02 - 2022 RZR PRO R / PRO R 4 Service Manual
© Copyright Polaris Industries Inc.
1.39
SPN COMPONENT
FMI CONDITION CODE
20 Data Drifted High C1162
1888 PTO Solenoid Driver Circuit
3 Voltage Above Normal, Or Shorted To High Source P1311
4 Voltage Below Normal, Or Shorted To Low Source P1312
5 Current Below Normal Or Open Circuit P1310
2584 Brake Pressure Switches
3 Voltage Above Normal, Or Shorted To High Source C2244
4 Voltage Below Normal, Or Shorted To Low Source C2044
13 Out Of Calibration C1263
17 Data Valid But Below Normal Operating Range - Least Severe Level C2144
20 Data Drifted High C1164
2590
Vehicle Speed
16 Data Valid But Above Normal Operating Range - Moderately Severe
Level
P1500
2596
Speed Key Selected Maximum
Vehicle Speed Limit Message
19 Received Network Data In Error U255A
31 Condition Exists U2259
2629
Engine Turbocharger 1
Compressor Outlet Temperature
3 Voltage Above Normal, Or Shorted To High Source P1235
4 Voltage Below Normal, Or Shorted To Low Source P1236
3056
Oxygen Sensor Bank 1 Sensor 1
2 Data Erratic, Intermittent Or Incorrect P0130
3 Voltage Above Normal, Or Shorted To High Source P0132
4 Voltage Below Normal, Or Shorted To Low Source P0131 / C1049
12 Bad Intelligent Device Or Component P113A
17 Data Valid But Below Normal Operating Range - Least Severe Level C2049
3057
Oxygen Sensor Bank 1 Sensor 2
2 Data Erratic, Intermittent Or Incorrect P0136
3 Voltage Above Normal, Or Shorted To High Source P0138
4 Voltage Below Normal, Or Shorted To Low Source P0137
3597
ECU Output Supply Voltage 1
0 Data Valid But Above Normal Operational Range - Most Severe Level P16A3
1 Data Valid But Below Normal Operational Range - Most Severe Level P16A6
3 Voltage Above Normal, Or Shorted To High Source P16A2
4 Voltage Below Normal, Or Shorted To Low Source P16A1
16 Data Valid But Above Normal Operating Range - Moderately Severe
Level
P16A5
18 Data Valid But Below Normal Operating Range - Moderately Severe
Level
P16A7
3598
ECU Output Supply Voltage 2
0 Data Valid But Above Normal Operational Range - Most Severe Level P16AA
1 Data Valid But Below Normal Operational Range - Most Severe Level P16AC
3 Voltage Above Normal, Or Shorted To High Source P16A9
4 Voltage Below Normal, Or Shorted To Low Source P16A8
16 Data Valid But Above Normal Operating Range - Moderately Severe
Level
P16AB
18 Data Valid But Below Normal Operating Range - Moderately Severe
Level
P16AD
3599
ECU Output Supply Voltage 3
0 Data Valid But Above Normal Operational Range - Most Severe Level P17AC
1 Data Valid But Below Normal Operational Range - Most Severe Level P17AE
3 Voltage Above Normal, Or Shorted To High Source P17AA
4 Voltage Below Normal, Or Shorted To Low Source P17AB
16 Data Valid But Above Normal Operating Range - Moderately Severe
Level
P17AD
GENERAL INFORMATION
