9928492 R04 - 2017-2018 RZR XP 1000 / XP4 1000 Service Manual
© Copyright Polaris Industries Inc.
3.13
8. Lift the cover from the housing and remove the
thermostat.
NOTE
Thermostat has a pop-off relief to allow the bypass
system to operate until thermostat opens.
9. Install a new thermostat with the bleed hole
r
positioned closest to the engine.
NOTE
Image shown above is with engine removed for clarity.
10. Reverse this procedure for installation. Torque
thermostat cover bolts to specification.
TORQUE
Thermostat Cover Bolts:
7 ft-lb (10 Nm)
11. Be sure to properly fill and bleed cooling system as
outlined in this chapter.
ENGINE / COOLING SYSTEM
