REAR BRAKE LINES - JUNCTION BLOCK TO CALIPERS
NOTE
Brake lines route inside the stabilizer bar and shock mounts as shown.
q
Brake Line Retaining Clip
r
Trailing Arm Brake Line Retainer
BRAKE SYSTEM
To Next Page
