5.12
9928492 R04 - 2017-2018 RZR XP 1000 / XP4 1000 Service Manual
© Copyright Polaris Industries Inc.
TORQUE
Driven Clutch Retaining Bolt:
55 ft-lb (75 Nm)
14.Install the drive belt noting direction of belt rotation
(see Chapter 5 – Belt Installation, page 5.14). If a new
belt is installed, install so numbers can be easily read.
15.Install a new outer clutch cover seal with the colored
stripe facing the inner clutch cover.
16.Reinstall outer clutch cover and secure with screws.
Torque screws to specification.
TORQUE
Outer Clutch Cover Retaining Screws:
48 in-lb (5 Nm)
17.Install inlet and outlet ducts and tighten hose clamps.
18.Install the left rear shock lower mounting bolt and the
left rear wheel. Torque fasteners to specification.
TORQUE
Rear Shock Mounting Bolt:
70 ft-lbs (95 Nm)
TORQUE
Wheel Nuts:
120 ft-lbs (163 Nm)
PVT SYSTEM
