6. Torque wheel hub nut to specification and install a
new cotter pin
t
. Tighten nut slightly if necessary to
align cotter pin holes.
TORQUE
Hub Castle Nut:
110 ft-lbs (149 Nm)
7. Install wheel and four wheel nuts. Torque wheel nuts
to specification.
TORQUE
Wheel Nuts:
120 ft-lbs (163 Nm)
8. Rotate wheel and check for smooth operation. Bend
both ends of cotter pin around end of spindle in
different directions.
