9928492 R04 - 2017-2018 RZR XP 1000 / XP4 1000 Service Manual
© Copyright Polaris Industries Inc.
8.25
RZR XP 1000 / LE Front Shock Valving
COMPRESSION REBOUND
CLICKER
ASSEMBLY
0.900 x 0.008 0.900 x 0.015 0.700 x 0.010
0.900 x 0.010 0.900 x 0.012
CLICKER
PISTON
1.450 x 0.010 1.450 x 0.015 1.100 x 0.025
0.900 x 0.008 1.450 x 0.015 1.000 x 0.025
1.450 x 0.015 1.450 x 0.008 1.000 x 0.025
1.300 x 0.015 1.450 x 0.008 0.625 x 0.065
1.200 x 0.015 1.300 x 0.010
1.100 x 0.015 1.000 x 0.008
1.000 x 0.015 1.500 x 0.120
0.750 x 0.065
Piston Bleed Orifice: none
RZR XP 4 1000 Front Shock Valving
COMPRESSION REBOUND
CLICKER
PISTON
1.550 x 0.008 1.500 x 0.010 1.100 x 0.025
1.000 x 0.015 1.100 x 0.010 1.000 x 0.025
1.550 x 0.008 1.450 x 0.010 1.000 x 0.025
1.550 x 0.008 1.300 x 0.010 0.625 x 0.065
1.550 x 0.008 1.200 x 0.010
1.550 x 0.008 1.100 x 0.010
1.550 x 0.008 1.000 x 0.010
1.450 x 0.010 0.900 x 0.010
1.300 x 0.008 0.750 x 0.065
1.200 x .012
1.100 x .012
0.750 x 0.065
Piston Bleed Orifice: none
RZR XP / XP4 1000 High Lifter Front Shock
Valving
COMPRESSION REBOUND
CLICKER
ASSEMBLY
1.550 x 0.008 1.300 x 0.015 0.700 x 0.010
1.000 x 0.015 1.300 x 0.015
CLICKER
PISTON
1.550 x 0.008 1.200 x 0.012 1.10 x 0.012
1.550 x 0.008 1.100 x 0.012 0.700 x 0.006
1.550 x 0.008 1.000 x 0.012 1.00 x 0.025
1.550 x 0.008 0.900 x 0.012 0.625 x 0.065
1.550 x 0.008 1.000 x 0.095
1.450 x 0.010
1.300 x 0.008
Piston Bleed Orifice: 0.100”
STEERING / SUSPENSION
