Shock Valving RZR XP / XP4 1000 High
Lifter
COMPRESSION REBOUND
CLICKER
ASSEMBLY
1.850 x 0.010 1.500 x 0.010 0.700 x 0.010
1.750 x 0.010 1.450 x 0.010
CLICKER
PISTON
1.650 x 0.010 1.300 x 0.010 1.000 x 0.015
1.550 x 0.008 1.200 x 0.010 1.000 x 0.015
1.000 x 0.010 1.100 x 0.010 0.900 x 0.015
1.550 x 0.008 1.000 x 0.010 0.600 x 0.015
1.550 x 0.008 0.900 x 0.010 0.600 x 0.015
1.550 x 0.008 0.800 x 0.010
1.550 x 0.008 1.000 x 0.095
1.550 x 0.008
1.450 x 0.010
1.300 x 0.012
1.200 x 0.012
1.500 x 0.125
Piston Bleed Orifice: 0.100″
