11
9928492 R04 - 2017-2018 RZR XP 1000 / XP4 1000 Service Manual
© Copyright Polaris Industries Inc.
11.13
q
Vehicle Speed Display - Analog display of vehicle speed in MPH or km/h.
w
Information Display Area - Odometer / Trip Meter / Tachometer / Engine Temperature / Engine Hours
/ Service Info / Clock - LCD display of the service hour interval, total vehicle miles or km., total engine
hours, a trip meter, engine RPM and engine temperature.
e
MPH / KM/H Display - MPH is displayed when the instrument cluster is in the Standard mode. KM/H is
displayed when the instrument cluster is in the Metric mode.
r
High Beam Indicator - LED icon illuminates whenever the Headlamp switch is in the high beam position.
t
Fuel Level Indicator - LCD bar graph indicating current fuel level. All segments will flash when the fuel
level is very low.
y
Clock - Displays current time in either 12-hour or 24-hour formats.
u
Engine Temperature Indicator - LED icon illuminates when the ECM determines the engine is
overheating. The indicators will initially flash to indicate the engine is overheating. The indicators will stay lit
and not flash if a severe overheating condition exists.
i
Service Interval Indicator - Preset at the factory and adjustable by the user, a flashing wrench symbol
alerts the operator that the preset service interval has been reached and maintenance should be
performed. The wrench icon will flash for 10 seconds upon start-up once it reaches 0.
o
Check Engine MIL - Illuminated when the ECM has detected a Diagnostic Trouble Code in the engine
management system.
a
AWD Indicator - Illuminated when the AWD / 2WD switch is in the AWD position.
s
Differential Unlocked Indicator - If equipped with Turf Mode, will illuminate when the AWD switch is in
Turf mode..
d
Neutral Gear Indicator - LED icon illuminates when gear selector is in the neutral (N) position.
f
Gear Position Indicator - Displays gear selector position.
P = Park
R = Reverse
N = Neutral
H = High Forward Gear
L = Low Forward Gear
– = Gear Signal Error (shifter stuck between gears)
g
Power Steering System MIL - LED icon illuminates when a fault has occurred in the EPS system. This
indicator also turns on momentarily when the key is turned on.
h
Turn Signal / Hazard Lamp Indicator - If equipped with turn signals, the LED icon illuminates whenever
the left, right or hazard blinker is activated.
j
Helmet / Seat Belt Indicator - LED icon illuminates for several seconds when the key is turned to the ON
position as a reminder for the riders to properly use safety equipment. The lamp stays illuminated until the
driver’s seat belt is properly latched.
k
Hours Indicator - Illuminates when Hours are being displayed on the Information Display
l
Mode Button - Used to move through the menu features.
ELECTRICAL
