61
Maintenance
Fuel Tank Installation
10. Install the rear isolators (with flange side toward
the tank) and flange bushings.
11. Lower the tank and install the tank bolts.
Torque: 18 ft-lbs (24 Nm)
12. Connect the vent line, ground wire and ground
wire bolt.
Torque: 96 in-lbs (11 Nm)
13. Prime the fuel pump. See page 45.
14. Check for leaks.
15. Reinstall the seat and side covers.
To Next Page
