101
Specifications
CROSS ROADS CROSS COUNTRY
Dimensions (Dimensions and specifications may vary with features, options and accessories)
Overall Length 104.4 in. (265 cm) 104.4 in. (265 cm)
108.2 in. (274.8 cm) w/Trunk
Overall Width 36 in. (91.4 cm) 39.2 in. (99.5 cm)
Overall Height 56.3 in. (143 cm) 53.2 in. (135.1 cm)
Seat Height 26.3 in. (66.8 cm) 26.3 in. (66.8 cm)
Wheel Base 65.7 in. (167 cm) 65.7 in. (167 cm)
Ground Clearance 5.8 in. (14.8 cm) 5.8 in. (14.8 cm)
Rake & Trail 29q/5.6 in. (14.2 cm) 29q/5.6 in. (14.2 cm)
Weight
Dry Weight 758 lbs. (345 kg) (HARD-BALL)
770 lbs. (349 kg) (Classic)
765 lbs. (347 kg)
800 lbs. (363 kg) w/Trunk
Wet Weight 793 lbs. (360 kg) (HARD-BALL)
805 lbs. (365 kg) (Classic)
800 lbs. (363 kg)
835 lbs. (380 kg) w/Trunk
Maximum Load Capacity (riders,
cargo, accessories, options)
580 lbs. (263 kg) 560 lbs. (254 kg)
525 lbs. (239 kg) w/Trunk
Gross Vehicle Weight Rating (GVWR)
(see page 14)
1360 lbs. (617 kg)
Gross Axle Weight Rating (GAWR) Front Axle: 460 lbs. (209 kg)
Rear Axle: 900 lbs. (408 kg)
CROSS ROADS / CROSS COUNTRY
Capacities
Engine Oil 5 qt. (4.75 l)
Approximately 4.5 qt. (4.25 l) at oil change
Fuel 5.8 gal. (22 l)
Fuel Reserve 1.2 gal. (4.5 l)
Engine
Engine Type
VICTORY Freedom
106 / 6 V-Twin
Configuration 50q V-Twin 4 Stroke SOHC
Displacement 106 Cubic Inch (1731 cc)
Cooling System Air & Oil
Compression Ratio 9.4:1
Valve Train 4 Valves per cylinder, Hydraulic Lifters & Self-Adjusting Cam Chains
Bore & Stroke 101 x 108 mm
Throttle Body Bore 45 mm
Electronic Fuel Injection System Closed Loop
Lubrication System Wet Sump
Spark Plug / Gap NGK DCPR6E / .031-.035 inch (0.8-0.9 mm)
Exhaust Split dual exhaust with crossover
To Next Page
