79
Maintenance
Handlebar Position
On models equipped with two handlebar positions, the motorcycle is
manufactured with handlebars in the low position. Before changing
handlebar position, check regulations in your area of operation.
Operation with the handlebars in the high position may not be legal
in all areas or for all riders.
WARNING! Handlebar controls must be repositioned each time handlebar
position is changed. Failure to reposition handlebar controls could result in
loss of vehicle control resulting in severe injury or death.
1. To adjust handlebar position, loosen
the bolts on the bottom of the riser.
2. Adjust the handlebars upward or
downward to the desired position.
For high position, align the upper
handlebar marks with the split in
the riser. For low position, align the
lower handlebar marks with the
split in the riser.
3. Tighten the front (longer) riser bolts first, then
tighten the rear bolts.
Torque: 22 ft-lbs (31 Nm)
4. Loosen the screws at the bottom of the left and
right handlebar controls and reposition both
controls. Make sure the index pin in each
control is fully seated in the appropriate
handlebar hole before tightening screws. For
handlebars in the low position, seat the index
pins in the forward set of index holes. For
handlebars in the high position, seat the pins in
the rear set of holes.
5. Tighten the handlebar control screws.
Torque: 25 in-lbs (2.8 Nm)
High
Position
Low
Position
High
Position
Align upper
mark to split.
Low
Position
Align lower
mark to split.
Low Position
Use forward holes.
High Position
Use rear holes.
Index Pin
