Polyaire airtouch - Page 60

60
R
S
4
8
5
A
+
B
-
H
o
m
e
K
it
S/A2
E/M T Z1 Z2 Z3 Z4
Z8 Z7 Z6 Z5 B2 B1
L N
RS485
A+ B-
S3
S4
S1
S/A1-2: Supply Air Sensors
E/M: Extension Module T: Touchscreen Z1...Z8: Zone Dampers L and N: 24V AC Power Supply
B1 and B2: Bypass Dampers
HomeKit: HomeKit Module
RS485: AC Gateway
AC Gateway
F3 F4
F3 F4
AirTouch 4
S/A1
V1 V2
V1 V2
657211 (RS485 Cable) from Polyaire
(Provided with the gateway)
Master/Slave Setting
S1 S4
Gateway As
0000 0000
Slave
1000 0000 Master
Four Core cable, stripped wires
field prerpared
AC Indoor PCB
Gateway Address Setting
S3
Gateway Address
10000001 1 01000001
2
11000001 3 00100001 4
657217
Note:
1. 0-Off, 1-On, x-On
2. This applies to gateways made in Spain
No-NASA (
657217
)
Wiring Diagram - Old Version
Wiring Diagrams contd.
