Polycom SoundPoint IP 430 Quick Tip

Quick Tip
SoundPoint ® IP, SIP 3.1.0
2
SoundPoint IP Phone Terminology
Before you read this document, it is important to understand the following
phone-related terminology:
• Attendant phone—The phone you use to monitor a remote line. The
phone has optional Expansion Modules and is set up to monitor one or
more remote lines using the BLF feature.
• Remote line—The remote line the attendant phone monitors.
• Idle state—The phone is “on hook” and there are no active, held, or
incoming calls.
• Active state—There is an active call in progress.
• Alerting state—There is an incoming call (the phone is ringing, if
configured with a ring tone).
• Call waiting state—There is an active call in progress and the phone is
ringing. (There may be held calls also.)
• Directed call pickup—You can answer an incoming call on a remote line.
The following figure shows a SoundPoint IP 650 and the parts of the phone
that are mentioned in this quick tip.

Polycom SoundPoint IP 430 Specifications

Display

display resolution	132 x 46 pixels
message waiting indicator	Yes

Power

power over ethernet support	IEEE 802.3af
external AC adapter voltage	24V DC
power consumption	3.0W nominal (3.8W max)

Operating Environment

operating temperature range	10 to 40 degrees C (50 to 104 degrees F)
operating relative humidity	20% to 85%, non-condensing
storage temperature range	-40 to +70 degrees C (-40 to +160 degrees F)

Weight and Dimensions

dimensions	21 cm x 16.5 cm x 18 cm x 3 cm
shipping weight	1.9 kg
