HOT WATER COIL CAPACITIES
Table 3-5. Hot Water Coil Capacities
Section III: Performance and Sizing
Vertical (AWV, HCDV) Models 1 Row Hot Water Coil
Model
Flow Rate Range (GPM) Heating Capacity Range (MBH)
Min Max Min Max
0550 5 15 35 56
0800 5 15 44 69
1200 5 15 48 75
1400 10 25 73 109
1800 10 25 82 115
2600 15 35 108 166
3500 20 40 165 248
4000 20 40 165 248
Horizontal (AWH, HCDH) Models 1 Row Hot Water Coil
Model
Flow Rate Range (GPM) Heating Capacity Range (MBH)
Min Max Min Max
0550 5 15 33 54
0800 5 15 43 66
1200 5 15 48 75
1400 10 25 71 105
1800 10 25 80 111
2600 15 35 104 161
3500 20 40 147 203
4000 20 40 158 209
Horizontal (AWH, HCDH) Models 2 Row Hot Water Coil
Model
Flow Rate Range (GPM) Heating Capacity Range (MBH)
Min Max Min Max
0550 15 25 54 84
0800 15 25 76 108
1200 15 25 87 123
1400 20 35 115 168
1800 20 35 134 180
2600 30 50 167 258
3500 35 55 237 326
4000 35 55 260 340
NOTE
Coils add 0.1”WC to ESP
Entering Air Temperature - 80°F
Entering Water Temperature - 180°F
Max. Working Pressure - 125 psi
Capacity is a function of Return Airow and is independent of
Supply Airow
