PoolPak HCD 1200 - Figure 3-3. Air-Cooled Condenser (Poolpak) - Isometric Views; Figure 3-4. Air-Cooled Condenser (Bohn) - Elevation Views

24 EGW06-PCPEG-20140813
TM
TM
Section III: Performance and Sizing
Figure 3-3. Air-Cooled Condenser (PoolPak™) - Isometric Views
PCP_EG_ACC_PoolPakMfgr_20140122.eps
Figure 3-4. Air-Cooled Condenser (Bohn) - Elevation Views
PCP_EG_ACC_Bohn_20140122.eps
SINGLE FAN DUAL FAN
*ALL DIMENSIONS ARE IN INCHES
45.4
42.3
43 130
120
38
49.1
24.5
16
21.5
9
8
OPTIONAL EXTERNAL
ELECTRICAL BOX
1
17
34
0.875 DIA. MTG.
HOLES TYP.
0.875 DIA. MTG.
HOLES TYP.
B-VAPOR CONNECTION
C-LIQUID CONNECTION
127
106
112
20.25
A
A
VIEW A-A
A
A
VIEW A-A
DUAL FAN (BOHN)
THREE FAN (BOHN)
ALL DIMENSIONS ARE IN INCHES
