Section III: Performance and Sizing
REMOTE AIR-COOLED CONDENSER (ACC)
Table 3-8. Remote ACC Performance Chart
Note: Below table contains the piping sizes of the remote ACC stub-outs. Additional eld piping may be needed to make
the transition from the connections to correct refrigeration lineset sizing (See Table 4-3.)
Unit Size
ACC
Model*
Ambient Temp
(°F)
Unit
Height
(inches)
Vapor
O.D.
(inches)
Liquid
O.D.
(inches)
Unit
Weight
Motor FLA
Min. Circuit
Ampacity
A B C 208/230V 460V 208/230V 460V
0550 ACC0041 95/100/105/115 39.3 5/8 1/2 120 3 1.5 3.8 1.9
0800
ACC0041 95/100/105
39.3
5/8 1/2 120
3 1.5 3.8 1.9ACC0051 110 3/4 1/2 120
ACC0081 115 7/8 5/8 210
1200
ACC0051 95/100/105
39.3
3/4 1/2 120
3 1.5 3.8 1.9
ACC0081 110 7/8 5/8 210
ACC0121 115 39.3 1-1/8 3/4 470 6 3 7.5 3.8
1400/1800
ACC0081 95/100/105 39.3 7/8 5/8 210 3 1.5 3.8 1.9
ACC0121 110/115 39.3 1-1/8 3/4 470 6 3 7.5 3.8
2600
ACC0121 95/100/105/110 39.3 1-1/8 3/4 470 6 3 7.5 3.8
ACC0301 115 49.0 1-1/8 7/8 640 14 7 20 15
3500
ACC0161 95/100/105 39.3
1-1/8 7/8
470 6 3 7.5 3.8
ACC0301 110
49.0
640
14 7 20 15
ACC0341 115 690
4000
ACC0161 95/100 39.3
1-1/8 7/8
470 6 3 7.5 3.8
ACC0211 105 40.5 550 10 5 11.2 5.6
ACC0301 110
49.0
640
14 7 20 15
ACC0341 115 690
*NOTES:For models ACC00XX, see gure #3-3 (Single Fan).
For models ACC01XX, see gure #3-3 (Dual Fan).
For models ACC02XX, see gure #3-4 (Three Fan-Bohn).
For models ACC03XX, see gure #3-4 (Dual Fan-Bohn).
