3.5 Connecting other functions
3. INSTALLATION
In order to ensure opmal heang of the SPA, regardless of the outside temperature, it is possible
to connect a relay to control the SPA heater, which in extreme condions will ensure good water
heang.
This relay is controlled by the heat pump control box either automacally or manually (boost).
As an opon, it is also possible to add an addional relay to control a circulaon pump if the
exisng ow rate in the installed SPA system is not sucient (recommended ow rate in the heat
pump around 1.5 to 2 m
3
/h).
In addion, it is possible to add an automac control (dry contact) that allows the heat pump to
start or not.
To do this, just remove the protecve cover to gain access to the corresponding terminal block and
connect the necessary wires.
Remove the protecve cover
(2 screws)
Connect the wires
