POWER ELECTRONICS
VS65
COMMUNICATION PROTOCOL
39
7.2.3. Register Information
 40001 command register
Bit Value Description
1 Starter starting
0
0 Hold mode
1 Starter shutdown
1
0 Hold mode
2 0 – 1 Reset starter
3 – 15 0 Unused
Example: To start the softstarter with the slave address 02. The controller sends 02 06 00
00 00 01. If the command is executed normally, the code 02 06 00 00 00 01 will be
returned. Checking the status register whether the starter started normally. If there is the
fault, the code 02 06 00 00 00 04 should be sent to reset.
 Register address 40002 state register
The state register reflects the state of soft starter, which is expressed with a word.
Bit Value Description
1 Starting state
0
0 Shutdown state
1 Running state
1
0 Shutdown state
1 Soft stop state
2
0 Shutdown state
1 Fault state
3
0 Normal state
4 – 15 Unused
Example: Reading the code of status 02 03 00 01 00 01
If the starter is in the starting process, the code 02 03 02 00 01 will be returned.
If a fault occurs to the starter, the code 02 03 02 00 08 will be returned.
 40003 current average value (hexadecimal system)
The value is VS65 average value of 3-phase actual current, which is shown in percentage
or actual value depending upon setting of the function code 0B.
Example: Read current value
Send the code 02 03 00 02 00 01.
If the current is 235A, the code 02 03 02 00 EB will be returned.
 40004 fault code (hexadecimal)
When the 3rd bit of status register 40002 is 1, VS65 is in fault status, with the fault code
being consistent with 6.1.
Example: Send 02 03 00 03 00 01
If the code 02 03 02 00 04 is returned, it means there is the input phase loss (fault code 04).
