CAUTION
The unit has a dangerous amount of voltage. If the UPS indicator is on, the
unit’s outlets may have a dangerous amount of voltage even when not
plugged into the wall outlet because the battery may continue to supply power.
Cares should be taken to undertake installation indoors free from electrically-conductive
particles which is under temperature and humidity control in order to reduce the risk of
electric shock. It is best to disconnect the device using the power supply cord. Ensure that
the equipment is placed in a position near the outlet where easily accessible. Except
replacing the batteries, all service on this equipment must be carried out by qualified
service personnel. Before conducting any maintenance, repair or shipment, first ensure
that everything is turned off completely and disconnected.
1. Introduction
The information provided in this manual covers on-line single phase 1KVA to 3VA UPS
(Uninterruptible Power System). This manual is about the basic functions, operating procedures,
emergency troubleshooting, and also including the information about on how to ship, store,
handle and install the equipment. Only detailed requirements of the UPS units are described
herein, and installation must be carried out in accordance with this manual. Electrical installations
must also carefully follow local legislation and regulations. Only qualified personnel should
conduct these installations as failure to acknowledge electrical hazards could prove to be fatal.
2. System Description
Several different kinds of sensitive electrical equipment stay protected by a UPS (Uninterruptible
Power System) including computers, workstations, process control systems, telecommunications
systems, sales terminals, other critical instrumentation, etc. The purpose of the UPS is to protect
these systems from poor utility power quality, complete loss of power, or other associated
problems.
Electrical interference abounds in many forms causing problems in AC power, from lightning,
power company accidents and radio transmissions to motors, air conditioners, and vending
machines, among others. So protection of sensitive electrical equipment is vital to protect against
power outages, low or high voltage, slow voltage fluctuations, frequency variations, differential
and common-mode noises, transients, etc.
In order to prevent power line problems reaching critical systems causing damage to software,
hardware and causing equipment to malfunction, the UPS helps by maintaining constant voltage,
isolating critical load output if needed, and provides clean utility AC power.
3. Storage
Please adhere to the following instructions if the UPS is not installed immediately:
Store the equipment as is in its original packing and shipping carton.
Do not store in temperatures outside the range of +15°C to +25°C.
Ensure that the equipment is fully protected from wet or damp areas and from moist air.
In order to maintain the vitality of the batteries, ensure that the UPS is recharged every 6 months
for at least 8 hours.
Storage and Transportation
Please handle the unit with extreme caution since a high amount of energy is contained with
the batteries. Always keep the unit in position as marked on the packaging and never drop the
unit.
