9. Technical Specifications
Tower Type
Model
1000
2000
3000
Configuration
Capacity (VA)
1000 VA
2000 VA
3000 VA
Capacity (Watts)
1000 W
2000 W
3000 W
Form
Tower Type
Phase
Single Phase
Energy Saving
Yes - ECO Mode Efficiency >94%
Input
Voltage
208 / 220 / 230 / 240 Vac
Input Voltage Range
120 - 276 VAC, < 25% Load
140 - 276 VAC, < 50% Load
160 - 276 VAC, < 75% Load
180 - 276 VAC, < 100% Load
Input Frequency Range
50 / 60 Hz (Auto Sensing)
Input Power Factor
>0.97
Cold Start
Yes
Output
Rated Power Factor
1.0
Waveform
Pure Sine Wave
Voltage
208* / 220 / 230 / 240 Vac ± 2%
Frequency
50 / 60 Hz ±0.25 Hz
Transfer Time
0 ms
Harmonic Distortion
≦ 2.5% THD at Linear Load
Crest Factor
3 : 1
EPO Function
Option
Protection
Overload
Line
Mode
105% - 120% for 30 seconds
121% - 150% for 10 seconds
Battery
Mode
101% - 109% for 10 seconds
110% - 120% for 3 seconds
Surge Protection
IEC 61000-4-5 Level 3
Bypass
Internal Bypass (Automatic and Manual)
Short Circuit Protection
UPS Output Cut Off Immediately
Battery
Bypass
Internal Bypass (Automatic and Manual)
Short Circuit Protection
UPS Output Cut Off Immediately
Type
12V 9Ah
12V 7Ah
12V 9Ah
Quantity
2
6
6
Sealed, Maintenance Free
Yes
Typical Recharge Time
4 hr to 90%
External Battery Module
Option
External Battery Connector
Option
Management & Communication
Indicator
LCD Control Panel
Communication Port
RS 232, USB B type
SNMP Slot
Option
Audible Alarms
Yes
Physical
Dimensions(WxDxH)(mm)
144 x 357 x 228
191 x 406 x 327
191 x 406 x 327
Weight (kgs)
10.4
20.3
22.9
Shipping Dimensions(mm)
249 x 448 x 359
292 x 500 x 455
292 x 500 x 455
Shipping Weight (kgs)
11.5
22.3
24.9
* While 208V output, capacity will be derated to 90%.
** Specifications are subject to change without further notice.
** Specifications are for reference, actual information should be based on real product.
