Powermatic PM2000B - Specifications

8
5.0 Specifications
Table 1
Model numbers
PM2000B & PM2000BT
Stock number – saw only
(see Table 2 below for kit configurations)
PM231B/PM231BT
PM251B/PM251BT
PM253B/PM253BT
Motor and Electricals
Motor type
Totally enclosed, fan cooled, induction
Horsepower
3 HP
5 HP
5 HP
Motor phase
1 PH
3 PH
Motor voltage
230 V
230/460 V
1
(prewired 230 V)
Cycle
60 Hz
Listed FLA (full load amps)
14.5 A
21 A
13 / 6.5 A
Motor speed
3450 RPM
Starting amps
86
126
120
Running amps (no load)
4.9
4.8
6.5
Start capacitor
400MFD 125VAC
400MFD 250VAC
n/a
Run capacitor
40µF 350VAC
30µF 500VAC
n/a
Power transfer
Poly-V belt
On/off switch
Magnetic switch, with safety key
Power cord and plug
not supplied
Recommended circuit size
2
20 A
30 A
20 A
Sound emission without load
3
84 db at 100cm; 89 dB at 50cm
Arbor and blade
Arbor diameter
5/8 in. (15.875 mm)
Arbor speed
4500 RPM
Arbor lock
yes
Arbor wrench
included
Blade included
Ø10 in. (254mm), 0.079 in. (2.0mm) thk, 0.118 in. (3.0mm) kerf,
40T, AB, carbide tips
Maximum depth of cut at 90 degrees
3-1/8 in. (80 mm)
Maximum depth of cut at 45 degrees
2-1/8 in. (54 mm)
Maximum rip to right of blade
30 in. (762 mm) or 50 in. (1270 mm)
Maximum rip to left of blade
13-1/2 in. (343 mm)
Dado maximum width
13/16 in. (21 mm)
Dado maximum diameter
8 in. (203 mm)
Blade tilt
Left, 0° to 45°
Table
Main table dimensions, L x W
30-1/2 x 22 in. (775 x 559 mm)
Table dimensions with extensions, L x W
30-1/2 x 42 in. (775 x 1067 mm)
Table area in front of blade at maximum height
11-1/4 in. (286 mm)
Table surface from floor, casters disengaged
35 in. (889 mm)
Miter T-slot, W x D
2 slots; 3/4 x 3/8 in. (19 x 10 mm)
Edge bevel
Front and rear
Dust collection
Dust port outside diameter
4" (101.6 mm)
Recommended minimum extraction volume
400 CFM (0.5 CMM)
