K2 – K3 Service Manual
12. K2-K3 SPARE PARTS LIST
KALIN
Part Number
Description
PCB position
SMD00611
K/LGT/ALIN/12+TEST+HSINK
RES00120
R52, R53
CA000200
ELET.1000UF 200V 25X35 SNAP IN 85° P10
C50 C51 C52 C53 C54 C55 C56 C57 C58
C59 C60 C61 C62 C63 C64 C65 C66 C67
C68 C69 C71 C72
DI000070
IRC 30EPH06
D9
DI000083
GSIB1580 PONTE A DIODI
D1 D2
DIS00007
5.1 VZ MMSZ5231B SOD123
D14
DIS00033
US1J DO214AC
D11,D13
DIS00030
13 VZ SML4743 DO214AC
D12
DIS00021
SS14 -E3/61T Schottky_Barrier_Rectifier
D44
DIS00026
BAS28 High_Speed_Double_Diode
D19
DIS00009
15 VZ MMSZ5245B SOD123
D71 D72
DIS00039
15 VZ 1W SML4744 DO214AC
D10 D18 D60
DS000009
HTSK-AL-OSA56-145 OXN HORZ. FINS REV.02 Taric.
76169990 90
SM000645
FU000032
Fuse 15A 250VDc (6x32mm) Fast UL Serie 3AB Fast Series
F1 F2
ICS00019
IR2156S SOIC14 BALLAST_CONTROL_IC SMD
U2
ICS00120
IRC IR1150ISTRPbF PFC One Cycle Control PFC IC
U1
IG000003
IRG4PC50UDPbF N-Channel Gate Bipolar Trans IGBT 600V 50A
TO-247AC
Q11 Q12
IN000010
Switch Rocker Single Pole SP-ON 6A 250Vac 13-Round Body
(Ø=20.2)mm Color
ME364
IS000041
HI-FLOW300 145x32 AMPL.KALIN.LGT $1,25
1 pc. X channel
ML000001
MOLLE Q&D INOX
2 pc. X channel
ML000007
MOLLE K&Q&D INOX SP. 1.2
13 pc. X channel
MO000038
FCH47N60F_F133 NChannel_SuperFET Vds=600V
ID@25°C=47A Pd=417W TO-247 PTH
Q3 Q4 Q5
RE000335
NTC 2 Ohm 12A 20% P5.1W (21x7x28)mm Pitch 7.5mm S364
Series CONF(100)
R54
TO000099.2
"K-LGT" RES.CONV.TRASF.135015 E42/21/15 3C92 CSA from
20/09 Furukawa
T5 T6 (ORA SONO CSA)
TR000003
BDW93CFP NPN_Darlington_Power_Transistor Vceo=100V
Pd=33W 100<hFE@10A(Ic)3V(Vce)<20000 TO220FP PTH
Q13 Q14
TRS00009
PBSS5320T PNP_Transistor Vceo=-20V Ic=-2A Pd=300mW(su
footprint standard) hfe=220_max SOT23 SMD
Q2 Q8 Q10
TRS00010
PBSS4320T NPN_Transistor Vceo=20V Ic=2A Pd=300mW(su
footprint standard) hfe=220_max SOT23 SMD
Q1 Q7 Q9
VN000025
ADDA AB1212XB-Y01 12V 1.4A Ieff=1.12A v=3100rpm
Airflow_Max=36.323CFM N=57dB/A W120.5D120.5H32mm
SM000645
VR000007
VARISTOR S20K385 EPCOS CONF(200)
RV1
