INDEX
13
T-SERIES | SERVICE MANUAL
5.2.3 Main Board MOSFETs & Diodes Layout
PFC 1
MOSFETs
PFC 2
MOSFETs
PFC 2
Diodes
PFC 1
Diodes
CH 1
MOSFETs
CH 2
MOSFETs
CH 3
MOSFETs
CH 4
MOSFETs
