T-SERIES | SERVICE MANUAL
5.2.5 Rear Board Layout
Colour Description
Output Port 1 & 2
AES3 input & Output
Analog Input Port 1 to 4
Network Ethernet & Dante Port 1 & 2
Layout
4CH Rear
2CH Rear
5.2.4 DSP Board Layout
Colour Description
Audio Control Section
DANTE Section
Layout
