300 Card Printer – User Guide
24
Card Types
Pure PVC card stock or laminated PVC/Polyester cards are available. The latter are more durable and better
suited to heavy use and heat lamination when required. For access control and Smart card applications, your
supplier should provide the appropriate type for direct to card printing. For consistent results, stick to a single
variety of good quality cards.
Generally, there are two standard sizes of card that can be used with the printer. These are as follows:
Physical Dimensions
CR80 = 3.375” x 2.125” (85.7 mm x 54.0 mm) (w x h)
CR79 = 3.303” x 2.051” (83.9 mm x 51.0 mm) (w x h)
Card thickness should be as follows:
Standard – 0.030” (0.76 mm).
Minimum – 0.020” (0.51 mm).
Maximum – 0.040” (1.02 mm).
Do not use any cards outside the printer card thickness specification 0.50 - 1.27mm (20 – 50 mil). To do so may
result in a card jam or damage within the printer and may not be covered under the manufacturer’s warranty.
Pixel Dimensions
CR80 Pixel dimensions:
1013 x 642 (w x h)
CARD VARIANTS
Card Part Numbers Product Variant
M9006 - 793 Premium Blank White Cards – CR80
M9006 – 794 Blank White Cards with Magnetic Stripe – CR80
M9007 - 011 Self-Adhesive Blank White Cards – CR80
M3610 – 054 Self-Adhesive Blank White Cards – CR80 (USA)
M9006 – 796 Holopatch Blank White Cards with Gold Square – CR80
M9006 – 797 Holopatch Blank White Cards with Gold Square and Magnetic Stripe – CR80
E9323 Blank Rewriteable Cards front & PVC back
