Model PD690 Universal Process Meter Instruction Manual
26
www.predig.com
Isolated 4-20 mA Transmitter Output Programming (ovtpvt)
The Isolated 4-20 mA Transmitter Output option can be programmed
without a calibrator. This option can be calibrated so that a 4 mA out-
put is produced for any number displayed by the meter. The 20 mA
output may be programmed to correspond to any number that is at
least 501 counts greater or smaller than the number corresponding to
4 mA. (Ex. 4 mA = 0, 20 mA = 501 or -501) If the span between 4 and
20 mA is less than 501 counts, an error message will appear and the
previously programmed values will be retained in memory until a
new set of values is accepted.
Setting 4 mA Output Value
1. Push ENTER, when ovtPvt appears push ENTER again.
2. All digits flash for 3 seconds, a green LED labeled "4" illuminates
indicating the flashing display is the value at which the meter will
produce a 4 mA output. Program desired value per
Five Basic
Digit/Display-setting Instructions
on page 19.
Setting 20 mA Output Value
1. When ENTER is pushed to complete the programming for 4 mA
output, the green LED labeled "20" illuminates indicating the
flashing display is the value at which the meter will produce a 20
mA output.
2. Program desired value per
Five Basic Digit/Display-setting
Instructions
on page 19.
3. An Error message will be displayed if the 4-20 mA output span is
smaller than 501 counts.
Programming Confirmation
The values that have been programmed to produce the 4 & 20 mA
outputs can be quickly checked to make sure they are the desired val-
ues. To do this, enter the ovtPvt routine by pushing ENTER and then
pushing ENTER again when ovtPvt appears.
The green "4" LED illuminates indicating the meter is displaying the
value at which it will produce a 4 mA output. Confirm that this is the
desired value. Push ENTER (within 3 seconds) before the entire dis-
play stops flashing and the green "20" LED illuminates indicating the
meter is displaying the value at which it will produce a 20 mA output.
Confirm that this is the desired value. Push ENTER (within 3 seconds)
before the entire display stops flashing and the meter returns to indi-
cation mode.
