Model PD690 Universal Process Meter Instruction Manual
11-POINT Input Range Minimum Span
LINEARIZATION Between Inputs
4-20 mA
(1.6 mA / (Number of points –1))
0-5 V (0.16 V / (Number of points -1))
0-10 V (0.32 V / (Number of points -1))
e.g. Minimum span for an 11-point, 4-20 mA calibration is 0.16 mA between inputs.
ALARM POINTS Four, any combination of high or low alarms.
ALARM POINT 0-100% of full scale, user selectable.
DEADBAND
ALARM STATUS Front panel LED.
INDICATION
LOCKOUT Jumper J3 restricts modification of
calibration values.
NON-VOLATILE All programming values are stored in non-
MEMORY volatile memory for a minimum of ten years if
power is lost. No battery needed.
NORMAL MODE 64 dB at 50/60 Hz
REJECTION
POWER
AC power, 115 or 230 VAC ±10%, 50/60 Hz, 10 VA.
DC Power, 18-36 VDC; 6 watts maximum.
ENCLOSURE 1/8 DIN, High Impact plastic, UL 94V-0
FRONT PANEL Type 4X, NEMA 4X, Panel Gasket provided
ENVIRONMENTAL Operational ambient temperature range: 0 to
+60°C. Storage temperature range: -40 to +85°C.
Relative humidity: 0 to 90% non-condensing.
WEIGHT 19.7 oz (559 g) (including options)
CONNECTIONS Removable screw terminal blocks (provided)
accept 22 to 12 AWG wire.
WARRANTY 2 years parts & labor.
EXTENDED 1 or 2 years, refer to the Price List for details.
WARRANTY
UL FILE NUMBER E160849; 508 Industrial Control Equipment
Options
Relays
RATING 2 or 4 SPDT (form C); rated 2 Amp @ 30 VDC
or 2 Amp @ 250 VAC resistive load;
1
/14 HP @
125 / 250 VAC for inductive loads.
7
www.predig.com
