Model PD690 Universal Process Meter Instruction Manual
www.predig.com
Alarm Programming
Overview
The meter is equipped with four alarm points as a standard feature.
Each alarm may be programmed for either a high or low alarm and
for 0-100% deadband. Front panel LEDs indicate alarm status.
Options for two or four relays are available.
To program a high alarm, program the set point above the reset point.
To program a low alarm, program the set point below the reset point.
To program the alarm deadband, set the reset point above or below
the set point by an amount equal to the desired deadband value.
Example: Alarm 2 is a high alarm that trips at 1500 and has a dead-
band of 100. Alarm 2 set point is set at 1500 and its reset point at
1400.
Setting Alarm Set & Reset Points (Alars)
Alarm Set and Reset points are programmed using the
Five Basic
Digit/Display-setting Instructions
described on page 19.
1. Push ENTER and when ALArS appears, push ENTER again. This
starts a scan of the four alarm set & reset points. The scan
sequence begins with a flashing display of alarm #1 set point. The
"1" LED and "S" LED below the display are illuminated to indicate
the meter is flashing alarm #1 set point value. Program the desired
value for alarm #1 set point using the
Five Basic Digit/Display-
setting Instructions
described on page 19.
2. After Alarm #1 set point has been programmed, the meter displays
Alarm #1 reset point, as indicated by the "1" LED and "R" LED
below the display. Program the desired value for alarm #1 reset
point using the
Five Basic Digit/Display-setting Instructions
described on page 19.
3. Program the remaining alarm set and reset points in a similar
fashion.
4.
When alarm programming is complete the meter will display the
process input signal and the front panel LEDs will indicate alarm
status.
27
