Model PD690 Universal Process Meter Instruction Manual
9
Display Messages and Functions
The following table describes the various messages displayed by the
meter during programming and operation:
Display Parameter Description/Comments
E-[AL Select External Set meter for calibration using
Calibration an external calibration source.
I-[AL Select Internal Set meter for calibration (scaling)
Calibration using Internal calibration source.
[ALIb Perform External Calibrate meter using an external
Calibration calibration source.
S[ALE Perform Internal Calibrate meter (scale) using
Calibration internal calibration source.
(scaling) (Signal source not required).
InPt 1 Input 1 Set Input 1 calibration value.
Dspy 1 Display 1 Set Display 1 calibration value.
Inpt 2 Input 2 Set Input 2 calibration value.
Dspy 2 Display 2 Set Display 2 calibration value.
DE[Pt Decimal Point Set decimal point or light up
extra "0".
No. PtS Number of Points Set meter for 2 to 11
calibration points.
L or S Linear or Square Set meter for Linear or Square Root
calibration/scaling.
[vtoFF Low-Flow Cutoff Set meter to display zero below
programmed cutoff point.
Alars Alarms Program alarm/relay set and
reset points.
OvtPvt Output Set 4-20 mA output values.
19999 Overrange Indicates input signal exceeds
full-scale range of meter.
-19999 Underrange Indicates input signal is below the
negative range of meter.
Error Error Indicates calibration was not
successful.
