COMMERCIAL PRODUCTS DIVISION
You do not need any special knowledge or experience to set up the EFX
®
. However,
because of the size and weight of the EFX, you will need to obtain appropriate
assistance during assembly.
ACQUIRE THE APPROPRIATE TOOLS
Obtain the following tools before assembling the EFX.
❑ Wire cutter
❑ Standard hex torque wrench
❑ ¹⁄₂-inch open-end or box-end wrench
❑ SAE Standard socket set
Note: After assembling the EFX, be sure to store the hex keys in a secure place.
The tools are used for maintenance procedures that are described in this manual.
INSTALLATION REQUIREMENTS
Follow these installation requirements when installing the EFX. If you do not
install the EFX according to the following guidelines, you could void the Precor
Limited Warranty.
• Set up the EFX on a solid, flat surface. Unpack and assemble the EFX close to
where you’ll use it. Make sure that the flat surface under the unit is smooth and
level. A level unit is required for the user’s safety and for proper operation.
• Provide ample space around the unit. Open space around the unit makes
for a safer mount and dismount.
• Fill out and mail the limited warranty card. To locate the serial number, place
yourself at the rear of the unit facing the display console, kneel down and look at
rear label near the power receptacle. (Refer to Diagram 2 on page 7.) Write the
serial number onto the Precor Limited Warranty card found on the back cover of
this manual. Return to page 7 and write the number there as well.
ASSEMBLY INSTRUCTIONS
To assist you in the assembly, the items in the Hardware kit, shown in Diagram 3,
correspond to a particular letter in the alphabet. These letters appear throughout the
assembly instructions. Refer to Diagram 3 on page 10.
1. Unpack the EFX
®
556i. Remove the packing materials and loose contents
(upper console assembly with electronic console, hardware kit, bracket
covers, and handrails) from inside the cardboard pockets and from around
the base frame assembly.
2. Pull the large cardboard piece away from the base frame assembly. Ask
for assistance to move the EFX
®
556i off the shipping pallet. You may need to
cut the tie wraps that hold the base frame and roller arms to the pallet.
Setting Up the EFX
®

Precor EFX556i Specifications

Performance

crossramp	25 degrees (fixed)
stride length	18 inches (46 cm)
resistance levels	1 - 20

Regulatory and Frame

frame	Powder-coated steel
regulatory approval	FCC, ETL, CE
power	Self

Weight and Dimensions

length	80 inches (203 cm)
width	30 inches (76 cm)
height	64 inches (184 cm)
weight	230 lbs (105 kg)
shipping weight	340 lbs (155 kg)
