Precor EFX556i User Manual

page 16
COMMERCIAL PRODUCTS DIVISION
CAUTION: A fully-assembled EFX is very heavy. To avoid possible in-
jury, obtain assistance.
10. If you need to move the EFX, ask someone for help. Lift the EFX from the
front and roll it into position on its rear wheels. See Diagram 11, #1.
11. Level the unit. Diagram 11, #2. To help keep the unit stable, the EFX has a
height adjuster at the front of the base assembly. Check to make sure that the
unit does not wobble from side to side or front to back.
To counteract any rocking motion, ask your assistant to grasp the upright
support and lift the front of the unit off the floor.
• To correct front to rear wobble, turn the height adjuster clockwise which
raises the height of the front end.
• To correct side to side wobble, turn the height adjuster counterclockwise
which lowers the height of the unit.
CAUTION: The height adjuster helps level the unit on uneven surfaces, but
cannot compensate for extremely uneven floors. Do not use the height adjuster
to raise or lower the unit more than ¾-inches.
SUPPLYING POWER TO THE EFX
®
556I
The EFX does not require an electrical power connection. It has an internal battery
that is recharged every time a user works out for a reasonable period of time. A
pedaling speed above 40 strides per minute must be maintained for several seconds
before the Precor banner appears on the display. Once the banner appears, the user
can press QUICKSTART or ENTER to begin working out. Refer to page 26, Exercis-
ing on the EFX , for more information.
Diagram 11
Roll the unit on its
rear wheels.
Rear wheels
Height adjuster
2
1

Precor EFX556i Specifications

Performance

crossramp	25 degrees (fixed)
stride length	18 inches (46 cm)
resistance levels	1 - 20

Regulatory and Frame

frame	Powder-coated steel
regulatory approval	FCC, ETL, CE
power	Self

Weight and Dimensions

length	80 inches (203 cm)
width	30 inches (76 cm)
height	64 inches (184 cm)
weight	230 lbs (105 kg)
shipping weight	340 lbs (155 kg)
