ID Qty PN Description
2 1
Q40052-101 MINI WALL BAR
3 2
CWWKCN010-019 WASHER, FLAT, STEEL, METRIC, M10 X
1.9MM THICK, CZ
4 2
CWWBWCN010-020 WASHER, SPLIT LOCK, M10 X 2.0MM
THICK, CZ
5 2
CWTECN010-035 SCREW,BHC,M10X1.5X35,CZ
Note: Part qty on a per unit basis.
b. Drill the three floor fixing anchor bolt holes per the floor fixing 25 bolt pattern diagram
shown below. The anchor bolt holes must be drilled perpendicular to the concrete sur-
face. Drill the anchor bolt holes per the manufacturers instructions, review "Floor Anchor-
ing Requirements" on page27.
18
4 Assembly and Installation
Procedure
