Set Points
STROKE COUNT: 0 to 999,999 strokes
BATCH COUNT: 0 to 999,999 strokes
QUALITY COUNT: 0 to 999,999 parts
PART COUNT: 0 to 4 parts/stroke
0 to 999,999 parts total
BATCH SIZE: 0 to 999,999 strokes
Limit switch angle: 0 to 359 degrees
Limit switch timer: 0 to 9999 milliseconds
Die sensor angle: 0 to 359 degrees
Speed Compensation: 0 to 99 degrees
MIN SPEED: 0 to 999 SPM
MAX SPEED: 0 to 999 SPM
Brake WARNING: 1 to 999 milliseconds
Brake FAILURE: 1 to 999 milliseconds
Brake ACTUAL: 1 to 999 milliseconds
(+/-1 millisecond
accuracy)
MOTION: 0 to 5.9 seconds (1/10-
sec increments)
DRIFT: preset to 2 SPM (1/10 SPM
increments)
Crank Angle: 0 to 359 degrees (1°
increments)
SPM: 0 to 999 strokes/minute
(+/- 1 SPM
accuracy)
Resolver
+/- 1º Resolution up to 600 RPM (+/- 2º
Resolution from 601 to 1000 RPM)
Shaft loading: Radial 400 lbs., Axial 200 lbs.
Standard cable 30’ (maximum length of 600’)
Construction
Stand Alone Unit
All 18 Gauge painted steel NEMA 12
lockable box with sealed front panel (see
dimensional information in System Installation
section).
Panel Mount Unit
All 18 Gauge painted steel NEMA 12
lockable box with sealed front panel (see
dimensional information in System Installation
section).
Temp. Range
0 to 50ºC
Dimensions
See “System Installation” section.
