Function Description
Remote Status
The J8 RS-232 port is normally used for the Servo Control 9600 baud 8N1 xon/xoff. The “Press Utility” REMOTE
menu is by default set to “RMT OFF”.
When the “Press Utility” REMOTE menu is set to “RMT ON”, the J8 RS-232 serial port is enabled for 57600 baud
8N1 xon/xoff Remote Status Commands (see table below). (see page 21 Remote Status section).
When the “Press Utility” REMOTE menu is set to “TCP ON”, the J8 RS-232 serial port needs to be connected to
the Optional Ethernet board. This 6.5” x 5.0” board contains an Ethernet Jack with built in Web server. The CD
that came with the Presscam 8 contains an Ethernet folder with the documentation on fi nding the IP address of
the Ethernet device and how to attach and run the board.
Command Function Return Size Return Format
String to PCS
$A: Job # Byte (0 to 255) @ job # &
$C: Press Angle Word (0 to 359) @ angle &
$D: SPM Word (0 to 999) @ SPM &
$E: Die Fault Byte (bit: 0=ok, 1=fault) @ die &
$F: PLS Status Byte (bit: 0=off, 1=on) @ PLS &
$G: Status Byte (see table) @ status &
$H: Fault codes1 Word (see Appendix A, each bit @ fault1 &
represents a fault code)
$I: Fault codes2 Word (see Appendix A, each bit @ fault2 &
represents a fault code)
$J: Fault codes3 Word (see Appendix A, each @ fault3 &
bit represents a fault code)
$K: StopTime Word (0 to 999 msec) @ stoptime &
$L: Runtime meter Long (in seconds) @ runtime &
$M: Strokes Long @ strokes &
$N: Parts Long @ parts &
$O: Batches Long @ batches &
$P: Tonnage CH 1 Word @ tonnch1 &
$Q: Tonnage CH 2 Word @ tonnch2 &
$R: Tonnage CH 3 Word @ tonnch3 &
$S: Tonnage CH 4 Word @ tonnch4 &
$T: Opto Input status Long (Each bit corresponding @ input &
to each input)
= Command String not completed within time allowed, reset command.
$ ASCII character sent to PressCommander to initiate command sequence
: ASCII character sent to PressCommander to complete command sequence
$ ASCII character sent from PressCommander to indicate valid initiate
! ASCII character sent from PressCommander to indicate command number received
@ ASCII character sent from PressCommander to indicate valid command number
? ASCII character sent from PressCommander to indicate invalid command number
& ASCII character sent from PressCommander to indicate end of transmission
Word 2 Bytes
Long 4 Bytes
PressCam 8 J8: RS-232 Remote Status Commands
