CONTROLS/INSTRUMENTS
Stop/Service/Reading lamp
FIGURE 61 23022A
1. Reading lamp
Can be adjusted manually to desired angle.
2. Reading lamp switch
Press to turn reading lamp ON or OFF.
3. Hostess signal switch
Depress rocker switch to activate chime in
driver's area. A light illuminates inside rocker
switch to indicate passenger position to the
hostess.
4. Driver's signal switch
Depress rocker switch to activate chime in
driver's area indicating to driver the passenger's
intention to disembark.
"Quick-Lounge" system (Optional)
"Quick-Lounge" is a quick-fit modular system
providing luxurious seating accommodations for
passengers.
This system occupies the same space as the
paired seating configuration it replaces. The
existing seat spacing remains unchanged.
Card tables
Two (2) card tables are supplied as standard
equipment and are used in the passenger swivel
seat configuration. The card tables are stored in
the parcel racks in separate stowage bags.
To install the card table, hold it at 45° (degrees) to
the side wall. Insert the spring-loaded pin first
into the hinge, then insert locking pin. Push on
the locking clamp to release the leg; then unfold
leg until clamp locks into place.
Galley (Optional)
The Mini-Chef galley can include features such as
a microwave oven and refrigerator to
accommodate hot/cold food and beverage
service. The galley's electrical power circuit is
activated by a rocker switch located on L.H. side
control panel (see item #13 on page 2-4).
Hubodometer (Optional)
A wheel hubodometer can be installed on the
R.H. side of the drive axle. It indicates the total
distance in miles or kilometers covered by the
coach since leaving the factory, including road
testing.
FIGURE 63 23024
FIGURE 62
23023
