CONTROLS/INSTRUMENTS
To operate driver side window and L.H.
windshield blinds, pull down tab to the required
position and then release; the blind will remain in
position. To raise blind, pull on release cord on
it's L.H. side.
To operate R.H. windshield blind, pull down tab
and position bar in hooks on central beam. To
raise blind, simply unhook bar then slowly lift
blind.
FIGURE 59 23020A
Each passenger window may also be provided
with a blind. Pull shade and lock in first or second
hook, as desired.
Adjustable A/C & heating louvers
The vehicle is supplied with five (5) adjustable
A/C & heating louvers. These can be adjusted
manually so the heated or cooled air flow can be
directed as desired.
Adjustable louvers are located as follows:
- One on L.H. side control panel.
- Two on L.H. side of driver's seat.
- One on center console.
- One over steps, near entrance door.
NOTE: The louver on L.H. side control panel
can be used to defrost driver's window or airflow
can be directed towards driver.
Mud flaps & splash guards
Mud flaps are installed behind front and tag axle
wheels in order to minimize dirt on the lower
panels of vehicle and to reduce stone projections
on vehicles behind you. Optional splash guards
may also have been installed behind each dual
wheel of the drive axle in order to reduce stone
projections on tag axle wheels.
FIGURE 58 23019
FIGURE 60 23021
