HP SPOT LUMINAIRE USER MANUAL
Light Shield
The Light Shield can be used to block light spill which may occur at some zoom angles.
To use the Light Shield, fold outward as shown below. If the Light Shield is not necessary, it can be folded backward.
Figure 2-10: Light Shield in Blocking Position
Note: When the Light Shield is extended, the luminaire spacing must be adjusted. Refer to Figure 2-6 on page 16.
