BEST BOY
®
HP SPOT LUMINAIRE USER MANUAL 39
DMX512 OPERATION
DMX Channel Mapping
Table 3-1: Best Boy DMX Channel Mapping
Channel Function Description 8-Bit 16-Bit
1 INTENSITY Intensity Adjustment home: 0
Out 0
Full 255
2 PAN Pan linear coarse adjustment home: 127 32768
0° 0
615° 255
3 Pan Fine Pan fine adjustment home: 0
4 TILT Tilt linear coarse adjustment home: 127 32768
0° 0
260° 255
5 Tilt Fine Tilt fine adjustment home: 0
6 CYAN Cyan Color Mix home: 0
Mix [Mode: Continuous] 0-255
Open 0
Full 255
Wheel Spin [Mode: Spin] 0-255
Clockwise 0-126
Fast 0
Slow 126
Stop 127-128
Counter-Clockwise 129-255
Slow 129
Fast 255
7 YELLO W Yellow Color Mix home: 0
Mix [Mode: Continuous] 0-255
Open 0
Full 255
Wheel Spin [Mode: Spin] 0-255
Clockwise 0-126
Fast 0
Slow 126
Stop 127-128
Counter-Clockwise 129-255
Slow 129
Fast 255
8 MAGENTA Magenta Color Mix home: 0
Mix [Mode: Continuous] 0-255
Open 0
Full 255
Wheel Spin [Mode: Spin] 0-255
Clockwise 0-126
Fast 0
Slow 126
Stop 127-128
