Timing Channels
Channel Functions
Timing channel control improves the timed moves of certain groups of parameters. Four timing channels are provided
for this purpose: Focus, Color, Beam, and Image.
Timing channels support time values of up to six minutes.
Timing Channel Mapping
Refer to the Timing Channels Table starting on the next page. The following guidelines apply:
+ A timing value of zero is full speed.
+ A time value of 100% (or 255 in DMX) causes the associated parameter(s) to follow cue fade time (console time)
rather than the timing channel.
+ Timing channels can be set in either % or 0-255 (DMX) modes, with the values assigned - as shown in the tables.
Table 3-2: Timing Channel Allocations
Channel Function Timing Channel
Pan
Focus
Tilt
Cyan
Color
Yellow
Magenta
Color Wheel
Zoom
Beam
Edge
Iris
Framing
Rotating Gobo Wheels 1 & 2
Gobo Index 1 & 2
Effects Wheel
Effects Index
