BEST BOY
®
HP SPOT LUMINAIRE USER MANUAL 15
Standard Hang
WARNING: The luminaire is heavy. Use caution when lifting.
WARNING: Two safety cables and at least two truss hooks should be used in all hang configurations.
To install in standard 2-point hang:
Step 1. Unpack case and attach Hanging Brackets. Refer to "Unpacking and Attaching Hanging Brackets" on
page 13.
Step 2. Roll case to mounting location as required (Figure 2-5).
Step 3. Using two people, carefully lift luminaire into mounting position on truss pipe.
Figure 2-5: Removing Luminaire From Case
