44 BEST BOY
®
HP SPOT LUMINAIRE USER MANUAL
Medium Random 103-106
Fast Random 107-109
Speed 110-255
Slow 110
Fast 255
30 MACRO Macro Control home: 0
None 0
Macro control overrides the
DMX control for that
parameter.
Iris - square wave 1
Iris - sine wave 2
Iris - sawtooth 3
Iris - reverse sawtooth 4
Iris close 5
Iris open 6
Zoom/Iris close 7
Zoom/Iris open 8
Framing - square wave 9
Framing - sine wave 10
Framing - sawtooth 11
Framing - reverse sawtooth 12
Framing close 13
Framing open 14
Zoom/Framing close 15
Zoom/Framing open 16
Iris/Framing alternate square wave 17
Iris/Framing alternate sine wave 18
Frost - sine wave 19
Frost - sawtooth 20
Frost - reverse sawtooth 21
Edge - sine wave 22
Edge - sawtooth 23
Edge - reverse sawtooth 24
Fire 25
Water 26
Clouds 27
31 MACRO SPEED Macro Speed control home: 0
Speed Range 0-246
Slow 0
Fast 246
Random Speed - Slow Rate 247-249
Random Speed - Medium Rate 250-252
Random Speed - Fast Rate 253-255
32 FOCUS TIME
Refer to "Timing Channels" on page 48
home: 255
33 COLOR TIME home: 255
34 IMAGE TIME home: 255
35 BEAM TIME home: 255
Table 3-1: Best Boy DMX Channel Mapping (Continued)
Channel Function Description 8-Bit 16-Bit
