Input Menu
Supply Air Temp and Neutral Mode
Scroll through with Up and Down buttons, press Menu button to apply your changes *---wait---* will display as changes are applied.
SERVICE MENU
INPUT

SUPPLY AIR TEMP
50.0°F
Supply Air Temperature (SAT) readout
· Shows current SAT reading.
· Range: -59.0°F – 300.0°F.
· No probe, means no sensor is connected.

NEUTRAL MODE
ENABLED
Neutral Mode = enabled
· Uses hot/cold switch points which are hard set.
· Not recommended.

NEUTRAL MODE
DYNAMIC
Neutral Mode = Dynamic
· When supply air temp (SAT) is below room temp it is considered cooling.
· When supply air temp (SAT) is above room temp it is considered heating.
· This mode is recommended because Prodigy will always use the supply air if it can help satisfy the room load.
Neutral Mode = Conventional
· Uses fixed supply air temp (SAT) to switch to cooling and heating
· Hot Switch - set SAT temperature to enable heating
· Cold Switch - set SAT temperature to enable cooling
Neutral Mode = Force Cool
· Locks the diffuser in the cooling mode
Neutral Mode = Force Heat
· Locks the diffuser in the heating mode

RM.TM.OFFSET
0.0°F
Plaque Temperature Offset
· Offsets the room temperature sensor.
· Default 0.0°F

PLAQUE OFFSET
0.0°F
Plaque Temperature Offset
· N/A

SAT OFFSET
0.0°F
Supply Air Temperature Offset
· Offset the SAT sensor
· Default 0.0°F

CONTACTCL1CFG
NO ACTION
Configure action of contact switch(s) 1 - 4
· When switch closed: No Action, Unoccupied mode, Occupied mode, Damper full open, Damper full closed
· Default: No Action

CO2 SENSOR
NOT DETECTED
Requires use of LCD Tstat with CO2 and Humidity Sensor
· CO2 Sensor = Detected
· CO2 Tweak = 0%
· CO2 Offset = 0% ppm

HUMIDITYSENS
NOT DETECTED
Requires use of LCD Tstat with CO2 and Humidity Sensor
· HumiditySens = Detected
· HumidityTweak = 0%
· HumidityOfset = 0% RH

PWR FRQ
60 Hz
Configure supply power frequency
· 60 Hz or 50 Hz

MOTOR SWITCH
OPEN
Read Only
· Indicates status of motor switch

MOTOR SWITCH
CONTACTED
Read Only
· Indicates status of last calibration

PRESS MENU
TO EXIT
Exit
